Cast Bearings with Housing | Space Saving Double Units

Premium Precision Cast Housing Bearings – Compact Dual Bearing Units

Discover our high-performance Bearings with Housing – Cast, Space Saving, Double Bearings series. These compact, heavy-duty bearing units are engineered for modern machinery where space is limited but reliability and load capacity cannot be compromised.

Designed with a robust one-piece cast iron or ductile iron housing and dual precision bearings, this series delivers superior rigidity, reduced vibration, and extended service life in a significantly smaller footprint.

Our Cast Housing Space-Saving Double Bearings feature a premium integrated design that combines two high-quality bearings within a single compact housing. This innovative configuration provides excellent radial and axial load support while minimizing installation space by 20-35% compared to traditional dual-bearing setups.

Manufactured using precision casting and CNC machining, the housings are made from high-strength HT200 or QT400 cast iron, offering outstanding durability, shock resistance, and corrosion protection. The units come pre-lubricated and are ready for immediate installation, making them ideal for both OEM equipment manufacturers and maintenance professionals.

Whether you need pillow block bearings, flange bearings, or compact plummer blocks, our double bearing housed units set a new standard for performance in tight spaces.

Cast Bearings with Housing Key Features & Benefits

1. Space-Saving Compact Design The dual-bearing configuration is optimized for minimal length and width. Perfect for compact machinery, conveyor systems, and automated equipment where every millimeter counts.

2. Double Bearing High Rigidity Two precision deep groove ball bearings or self-aligning bearings work together to distribute loads evenly. This results in higher load ratings, reduced shaft deflection, lower noise, and smoother high-speed operation.

3. Robust Cast Iron Housing Heavy-duty cast construction provides superior strength and vibration dampening. Available in pillow block, flange, and tapped-base styles with multiple mounting configurations.

4. Easy Installation & Maintenance Standard locking mechanisms including set screw, eccentric collar, or adapter sleeve. Greasable design with built-in lubrication channels for extended maintenance intervals or maintenance-free options.

5. Superior Sealing Performance Equipped with double-lip rubber seals or advanced labyrinth seals for excellent protection against dust, moisture, and contaminants. IP65-rated options available for harsh environments.

6. Wide Operating Range

• Bore diameters: 20mm to 100mm (custom sizes available)
• Temperature range: -20°C to +120°C (high-temp versions up to +200°C)
• Speed: Up to 5000 RPM depending on model
• High radial and axial load capacity

Wide Range of Applications

• Automation equipment and robotics
• Conveyor systems and material handling
• Agricultural machinery (harvesters, seeders, irrigation)
• Food & beverage processing and packaging machines
• Textile and printing machinery
• Warehouse logistics and roller conveyors
• New energy equipment (fans, solar trackers)
• CNC machines and woodworking equipment

Why Choose Our Space-Saving Double Bearing Units?

• Excellent Value: Premium quality at competitive prices — typically 60-75% of European or Japanese brands.
• Strict Quality Control: Every unit undergoes noise testing, dynamic balancing, and salt spray corrosion testing.
• Fast Delivery: Most standard models ready in stock. Custom orders ship within 7-15 days.
• Full Technical Support: Bearing selection guidance, 3D CAD models, load calculations, and installation drawings provided.
• Global Compliance: RoHS, REACH compliant. Food-grade grease options available.

How to Select the Right Bearing with Housing

To receive the best recommendation, please provide:

• Shaft diameter (bore size)
• Radial and axial load requirements
• Operating speed (RPM)
• Environmental conditions (temperature, moisture, dust)
• Preferred mounting style

Our expert team will help you choose the perfect Cast Space Saving Double Bearings solution for your application.

Bearings with Housing – Cast, Space Saving, Double Bearings deliver the perfect balance of compact design, high performance, and long service life. Trusted by hundreds of manufacturing companies worldwide for equipment upgrades and new machinery designs.

Ready to optimize your equipment? Contact us today for competitive pricing, samples, technical drawings, and fast global shipping. OEM and wholesale partnerships welcome.
